The PTO does shall not rotate when one of the two switches is in the OFF position
The following table explains how the PTO operates in two different positions (Manual & Auto) of the PTO
control switch with the PTO ON / OFF switch in the ON position.
z The table above provides information on PTO safety functions. If the indicator light on the instrument
panel flashes, this indicates to the operator that the PTO is in the ON position but is not currently
rotating temporarily because the implement is lifted.
The PTO starts to rotate immediately when the implement is lowered.
z The operator must observe the warning signal in order to ensure that there are no other persons or
bystanders in the area around the tractor, as rotating parts of some implements may accidentally
cause injury to persons near the tractor.
z Stopping the PTO when lifting the implement while controlling position shall prevent damage to the
implement or PTO.
PTO
ON/OFF
Switch
PTO
Control
Switch
Hydraulic Position
Control Lever.
PTO Monitor
Lamp on the dash panel
PTO SHAFT
On
Manual
Mode
Either raised or lowered Glows Rotates
On
Auto
Mode
Either raised or lowered Blinks Stationary
On
Auto
Mode
Raised Blinks Stationary
On
Auto
Mode
Lowered Glows Rotates
CONTROLS, INSTRUMENTS & OPERATIONS
