10. Appendixes
10.1 Printer parameters
Printer parameters
Printer mode Thermal printer
Resolution 203DPI (8 dots/mm)
Print width 72mm
Print contents ASCII code、Chinese 、 Image 、Barcode 、Curve、Symbol and so on
Fonts CII(12x24) ASCII(8x16) GBK(24x24) GBK(16x16) support multi-country language
Instruction ESC instruction set、CPCL instruction set
Barcode CodaBar、Code39、Code128、Code93、ITF、EAN-8 、EAN-13 、UPC-A、UPC-E
2-dimension code QRCode、PDF417、DataMatrix
Graphic print Image print, prestore-image print, curve print
Print speed About 60mm/s
Communication parameters
USB mini USB[It is a RS232 port also]
WiFi 802.11g/b / n support both STA & AP
Bluetooth Bluetooth 2.0 CLASS 2 SPP , Bluetooth 2.0 + 4.0
Others
Windows XP/7(PC) Support
Label gap detect Support
Black mark detect Support both left mark and right mark
Display OLED screen
Prompt Paper out prompt, Battery low prompt, Cover opened prompt
