16 Enclosure
16.1 Technical data ZETADYN 3C
16.1.1 ZETADYN 3C011 - 032
ZETADYN
3Cx011 3Cx013 3Cx017 3Cx023 3Cx032
Electrical data
Mains connection voltage [V] 3~ 180 ... 440 absolut
Mains frequency [Hz] 50 / 60 (±1,5 Hz)
Typ. motor output (400 V) [kW] 4.6 5.5 7.5 11 14
Duty cycle at rated current and clock frequency
8 kHz
[%] 60
Rated current for 60% duty ratio and clock
frequency 8 kHz fix
[A] 11 13 17 23 32
Rated current for 60% duty ratio and clock
frequency 12 kHz fix*
[A] 9 11 15 20 27
Rated current for 60% duty ratio and clock
frequency 16 kHz fix*
[A] 8 10 13 17 23
Max. operating current (for max. 10 s) [A] 20 24 31 42 58
Power loss at rated current, clock frequency
8 kHz and duty ratio of 60%
[W] 97 165 204 288 360
Power loss at rated current, clock frequency
16 kHz and duty ratio of 60 %
[W] 137 225 304 448 570
Power losses during standstill [W] 24 27
Power loss in stand-by 1 [W] 15 15 16 16 17
Power loss in stand-by 2 [W] 11 11 12 12 13
Switching frequency [kHz] 4 ... 16
Motor frequency [Hz] max. 200
Max. terminal cross-section line/motor [mm
2
] 6.0 6.0 6.0
Min. cable cross-section
Brake-Chopper / Brake-Resistor
[mm
2
] 2.5 2.5 2.5 2.5 6.0
Cable gland line with reduction
Cable gland line without reduction
[mm
2
]
[mm
2
]
9 - 15
11 - 21
-
11 - 21
Cable gland motor with reduction
Cable gland motor without reduction
[mm
2
]
[mm
2
]
12 - 15
14 - 21
-
14 - 21
Ambient conditions
Protection class
IP20
Ambient conditions operation [°C] 0 ... 55, from 40 °C power reduction by1.66% per 1 k temperature
increase
Relative humidity [%] 90 / condensation prohibited
Installation height [m über
NN]
bis 2000, ab 1000 m Leistungsreduzierung um 1% pro 100 m
Storage and shipping temperature [°C] -20 ... +60
Physical data
Weight [
kg] 24,9 25,1 25,3 29,7 30,2
Dimensions h x w x d [mm] 615 x 361 x 196,5
* With a variable clock frequency (menu power section/M_PWM=Auto) a power reduction does not take place.
Original operating instructions
ZETADYN 3C Enclosure
R-TBA08_03-GB 1619 Part.-No. 00163322-GB
1
87/204
