ZiLOG Z80 User Manual

15
Assembly Guide
Thisguide assumesyou arefamiliar withassembling circuitboards,soldering and
cleaning.If not, it isrecommendedyou readsomeof theguides onthe internet
beforecontinuing.
First check you haveall the requiredcomponents, aslisted in thesection “WhatYou
Need”. Header pins JP1and JP2, and P1to P4may needto becut fromlongerstrips.
Step 1
Fit
and
solder
IC
sockets
for
U1,
U2
and
U3.
Besure to fitthem with thenotch matchingthe legend on thecircuitboard,so you
do notend up fittingthe ICthe wrongway round too.
