ZiLOG Z80 User Manual

33
Contact Information
If you wishto contactme regardingthisdocument,or the hardwareand software it
relatesto, usethe contactpage atwww.scc.me.uk
StephenC Cousins, Chelmsford, Essex,United Kingdom.
RC2014 information
Informationaboutthe RC2014 system canbe foundat www.rc2014.co.uk
RC2014 support
Issuesrelatedto theRC2014 can bepostedon thegooglegroup “RC2014-Z80”.
RC2014 supplies
Partscan bepurchased throughTindie atwww.tindie.com (search “RC2014”)
OfficialRC2014 partsare at:
https://www.tindie.com/stores/Semachthemonkey/?ref=offsite_badges&utm_sour
ce=sellers_Semachthemonkey&utm_medium=badges&utm_campaign=badge_medi
um
Credits
Thanksto all those who provided encouragement, feedback and contributed ideas
to thedesign. Specifically:Mark T, Jon L, JayC, andanyone elseI forgot!
See RC2014 google group forfull details:
https://groups.google.com/forum/#!topic/rc2014-z80/JJ2JKAIehck

ZiLOG Z80 Specifications

General

Manufacturer	ZiLOG
Introduction Year	1976
Clock Speed	2.5 MHz to 20 MHz
Data Width	8-bit
Address Width	16-bit
Instruction Set	Z80
Transistor Count	8, 500
Package	40-pin DIP
Category	Microprocessor
Memory Address Space	64 KB
Voltage Supply	5V
