ZiLOG Z80 User Manual

6
1
U2 Z80 PIO,8MHz, Z84C2008PEG(or Z80 PIO,10MHz,
Z84C2010PEG), PDIP40
1
U2 socket 40pin PDIPIC socket0.6" wide
1
U3 74HCT08, quad2-input AND gate
1
U3 socket 14pin PDIPIC socket0.3" wide
Alsorequiredto assemble themodulefromthe above components:

Long
nose
pliers
 Side cutters
 Solderingiron
 Solder
 PCB cleaningmaterials

ZiLOG Z80 Specifications

General

Manufacturer	ZiLOG
Introduction Year	1976
Clock Speed	2.5 MHz to 20 MHz
Data Width	8-bit
Address Width	16-bit
Instruction Set	Z80
Transistor Count	8, 500
Package	40-pin DIP
Category	Microprocessor
Memory Address Space	64 KB
Voltage Supply	5V
