Device Set Up
6
Page 8
Therapy hose
connect
The therapy hose is connected and locket into the connecting piece of CryoMini.
Install glass plate
Put a silicone washer on each of the 4 spacing bolts mounted in the hood.
Then place the glass plate on the spacing bolts.
Attach the glass plate by screwing clamp bearings in each of the 4 spacing bolts. For
this, use the supplied U-tool.
Do not lift CryoMini on the glass plate!
Clamp bearings
Glass plate
Spacing bolt
