Page 3 of 16 Zip Hydroboil Plus - Installation & Operating Instructions - 86584UK - May 2012 v1.00
Note:
Read all instructions and precautions before proceeding. This unit must be
installed in accordance with water supply by-laws and relevant local authority
by-laws.
All plumbing and electrical installations must comply with local authority
requirements.
Contents
Read these warnings first . . . . . . . . . . . . . . . 4
Installation Requirements . . . . . . . . . . . . . . . 4
Installation Procedures . . . . . . . . . . . . . . . . . 5; 6
Step 1 – Positioning . . . . . . . . . . . . . . . 5
Step 2 – Fastening . . . . . . . . . . . . . . . . 5
Step 3 – Connecting . . . . . . . . . . . . . . . 6
a) Plumbing. . . . . . . . . . . . . . . . 6
b) Venting . . . . . . . . . . . . . . . . . 6
c ) Electrical . . . . . . . . . . . . . . . . 6
Step 4 – Assembling . . . . . . . . . . . . . . . 6
Step 5 – Commissioning . . . . . . . . . . . 6
Wall Mounting Template Dimensions . . . . . . 7
End of life disposal . . . . . . . . . . . . . . . . . . . . 7
Problem Solving. . . . . . . . . . . . . . . . . . . . . . . 8
Earthing Continuity Verification . . . . . . . . . . . 8
Tap Operating Procedures . . . . . . . . . . . . . . . 9
Operational Procedure Settings . . . . . . . . . . . 10
Default Settings . . . . . . . . . . . . . . . . . . . . . . . 11
Setting Operational Modes. . . . . . . . . . . . . . . 11
Normal Mode. . . . . . . . . . . . . . . . . . . . . . . . . 11
Configurational mode. . . . . . . . . . . . . . . . . . . 12,13
Spare Parts . . . . . . . . . . . . . . . . . . . . . . . . . . 14; 15
Warranty and Contact Details . . . . . . . . . . . . 16
