Page 14 of 16 Zip Hydroboil Plus - Installation & Operating Instructions - 86584UK - May 2012 v1.00
Spare Parts
Item Kit No. Description
1 90487 Cistern Lid Clamp Kit
2 90488 Cistern Lid and Gasket Kit
3 90490 Gasket Kit Hydroboil
4 90083 Float Valve Kit with Float
5 90069 Jumper Valve Kit with Seals
6 90102 Cistern Float Kit with Nut and Screw
7 90493 Metering Tube Kit 1500W
7 90494 Metering Tube Kit 2400W
8 90495 Banjo Screw Hydroboil
9 90496 O-Ring Kit Hydroboil
10 90743 Fascia Lens Kit
11 90741 Fascia Assy Electronic White
11 90742 Fascia Assy Electronic Grey
12 90620 Sensor Probe Econoboil Hot Tank Kit
13 90579 Overload Kit
14 90732 Tap Handle Kit
15 90733 Outlet Nozzle Kit
16 90503 Strap and Key Kit 3Litre Hydroboil
16 90504 Strap and Key Kit 5L& 7.5Litre Hydroboil
17 90505 Tap Nut Kit
18 90509 Tap Body Kit
19 90485 Element Kit 1500W / 240V
19 90486 Element Kit 2400W / 240V
20 90491 Cleaning Hole Cover Kit
21 90492 Drain Cap and Seal Kit
22 90107 Filter Kit Cold Inlet Bush
23 90131 Lid, Gasket and Clips Kit 3Litre
23 90132 Lid, Gasket and Clips Kit 5 Litre
23 90213 Lid, Gasket and Clips Kit 7.5 Litre
24 90142 Tank Welded Kit 3Litre
24 90734 Tank Welded Kit 5Litre
24 90735 Tank Welded Kit 7.5Litre
25 90147 Insulation Kit 3Litre
25 90736 Insulation Kit 5Litre
25 90737 Insulation Kit 7.5Litre
26 90130 Clips for Curled Tank Kit
27 90744 PCB Kit Hydroboil 2006
28 90214 Sensor Sleep Mode
