PARTS LIST
No.
Description
Quantity
No.
Description
Quantity
1
Main frame
1
36
Handle arm bearing
4
2
Front base
1
37
Bolt M8x80
2
3
Rear base
1
38
Handle arm sleeve
2
4
Handlebar post
1
39
Saddle height knob
2
5
Steering wheel
1
40
Handlebar post and handle arms’
sleeve
2
6 L/R
Left/right handle
1/1
41
Handle bearing
4
7 L/R
Handle arm, left/right
1/1
42
Handle sleeve
2
8 L/R
Pedal base, left/right
1/1
43
Curved washer D8xφ19x1.5xr30
4
9
Front base cap
2
44
Bolt M8xl50
4
10
Hexagonal bolt
1
45
Handle foam
2
11
Handling wheel
2
46
Handle cap
2
12
Flat washer D8xφ16x1.5
4
47
Computer
1
13
Locknut M8
2
48
Handlebar cap
2
14
Hexagonal nut M10
4
49
Hexagonal nut
4
15
Level foot
4
50
Handlebar foam
1
16
Flat washer φ10xφ20x2
8
51A/B
Handlebar post cover, A/B
1/1
17
Allen bolt M10*l58
4
52
Bolt M4x10
4
18
Spring washer D10
6
53
Bolt ST3x15
6
19
Rear base cap
2
54
AC adapter
1
20
Crank
2
55L/R
Pedal stabilising pad, left/right
1/1
21
Washer φ22xφ28φ0.3
2
56
Long axle
1
22
Allen bolt M8x16
8
57
Handlebar angle adjustment knob
1
23
Flat washer D8xφ20x2
2
58
Handlebar post bottom cover
1
24
Flat washer D8xφ38x2
2
59
Computer cable
1
25
Spring washer D8
2
60
Connecting cable
1
26
Hexagonal bolt M10x20
2
61
Curved washer D8xφ20x2xr30
2
27
Flat washer D10xφ20x2
2
62
Heart rate sensor cable
2
28
Lower handle arm
2
63L/R
Pedal base, left/right
1/1
29
Washer D40
2
64
Slotted-head bolt
1
30
Pedal base bearing
2
65
Locknut M10
2
31
Pedal base cap
4
66
Water bottle
1
32
Pedal base sleeve
4
67
Water bottle holder
1
33
Hexagonal bolt M8x45
6
68
Screw
2
34L/R
Left/right pedal
1/1
69
Flat washer
2
35
Bolt ST4.2x18
39
