CMP-200 User Manual

7 Control Board Wiring Installation

• Remove the wiring cover of the barrier gate main controller.

• Refer to the wiring diagram of the barrier gate controller and connect the

lines one by one firmly. (Note: Power must be disconnected before

installation or maintenance.)

• After checking and confirming reliable wiring, install the wiring cover

back.

• Install the Desktop Remote Control: Place the Desktop Remote Control on

the table in the guard room or attach it to the wall and plug-in the power.

The wiring diagram of the controller is as follows:
