ZKTeco MB10-VL Quick Start Guide

2
2.Device Installation
①Attach the mounting template sticker to the wall, and drill holes according to
the mounting paper.
②Fix the back plate on the wall using wall mounting screws.
③After passing the wires through the wiring hole and connecting them to the
device, and then attach the device to the back plate from top to bottom.
④Fasten the device to the back plate with a security screw.
Install on the wall
1 2
43
1.1m
①
②
Baseline

ZKTeco MB10-VL Specifications

General

Display	2.8-inch TFT Screen
Logs Capacity	100, 000
Communication	TCP/IP, USB Host
Operating Temperature	0°C to 45°C
Operating Humidity	20% to 80%
Matching Mode	1:N
Security Level	High
Standard Functions	DST
Optional Functions	ID Card
Verification Speed	≤1 second
Power Supply	12V DC
