ZKTeco MB10-VL Quick Start Guide

7
User Authentication
The terminal can detect the face within a range of 0.3m to 1.5m. The device switches to
the face verification interface automatically once it detects a change in environmental
brightness. The verification result shows the personnel details.
View records
View records on the software
Click [Device] > [Data] > [Transaction] on the software to view the records.
2020-12-3012:00
Successfully verified.
Name : Mike
User ID : 1
Verify : Face
Personnel
Person
Department
Pending Review
Custom Attributes
Parameters
Personnel ID Setting
The Maximum Length:
Support Letters:
Personnel ID Auto-increment:
Card Setting
The Maximum Length:
Card Format Display:
Pending personnel settings
Enable Auto-audit:
Self-service Registration
QR Code URL:
Yes No
Yes No
Bits(Binary)
Decimal Hexadecimal
Yes No
http://Server address:Port/app/v1/adreg
Download QR code image
9
32
Card Management
Personnel Registration
Personnel Registration
Personnel ID
First Name
Last Name
Last Name
Mike
4835
OK
2. The users will be displayed in [Personnel] > [Pending Review], click on [Review] option
and assign a department and click [OK] to successfully add the user.
Enable the declaration of health information:
Yes No

ZKTeco MB10-VL Specifications

General

Display	2.8-inch TFT Screen
Logs Capacity	100, 000
Communication	TCP/IP, USB Host
Operating Temperature	0°C to 45°C
Operating Humidity	20% to 80%
Matching Mode	1:N
Security Level	High
Standard Functions	DST
Optional Functions	ID Card
Verification Speed	≤1 second
Power Supply	12V DC
