ZKTeco TL800 User Manual

6
7
Install Batteries and Cover
Make sure that the Strike Box is aligned with the latch bolt. Then, use the installation
template to drill the holes.
1)
Align the Strike Plate and Box with the holes drilled and protect them with Screw A.
2)
8
Install Strike Plate and Box
Insert Lithium Battery and cover them with an OLED Screen model, then push back the
hidden cover.
Screw A
Indoor

ZKTeco TL800 Specifications

General

Brand	ZKTeco
Model	TL800
Category	Locks
Language	English
