Ed. 09/2009

Réf. : 1011463-11

Heat pump ...............................................................Instructions for installation and use

F

GB

P

I

1-2-3-4-5-6-7-8

Questions and Answers:

P
Pamela WilliamsAug 16, 2025
What causes high or low pressure fault in the refrigerating circuit of a Zodiac Heat Pump?
- W
  whitetinaAug 16, 2025
  A high or low pressure fault in the refrigerating circuit of your Zodiac Heat Pump can occur due to: * A mixture of water and air passing through the appliance. In this case, purge the hydraulic circuit. * Refrigerant overload. Consult a ZPCE-approved technician to check the refrigerant level. * Insufficient refrigerant. Consult a ZPCE-approved technician to look for leaks and refill refrigerant.
A
atkinsonannaAug 19, 2025
What causes a high pressure fault in the refrigerating circuit of a Zodiac Heat Pump?
- J
  Jonathan LoweAug 19, 2025
  A high-pressure fault in the refrigerating circuit of your Zodiac Heat Pump may be due to: * Water and air mixture passing through the appliance. To resolve this, purge the hydraulic circuit. * Refrigerant overload. Consult a ZPCE-approved technician to check the refrigerant level.
J
jesse96Aug 21, 2025
What causes a low pressure fault in the refrigerating circuit of a Zodiac Heat Pump?
- S
  Stacy RojasAug 22, 2025
  A low pressure fault in the refrigerating circuit of your Zodiac Heat Pump is caused by insufficient refrigerant. To resolve this, consult a ZPCE-approved technician to look for leaks and refill refrigerant.
N
Nicole PriceAug 25, 2025
What causes a voltage error on my Zodiac Edenpac 1?
- A
  Adam SmithAug 26, 2025
  A voltage error on your Zodiac Heat Pump indicates insufficient network power. Check the main power line and consult with the electrical network supplier.
A
ariasmatthewAug 27, 2025
What causes a phase order fault on a Zodiac three-phase heat pump?
- B
  Beth WilsonAug 27, 2025
  A phase order fault on your Zodiac three-phase heat pump can happen if: * There's incorrect wiring at the unit supply terminals. Check the wiring. * The electrical supplier modified the phase order. Contact your local electricity supplier. * There's a temporary failure of one or several phases.
J
jessica08Aug 30, 2025
Why does the anti-frost safety trigger on my Zodiac Heat Pump?
- D
  Dennis OwenAug 30, 2025
  The anti-frost safety on your Zodiac Heat Pump may trigger if the outside temperature is too low (below +5°C). Wait for a natural rise in the outside temperature.
R
robertwallaceSep 2, 2025
What does a control sensor fault mean on my Zodiac Heat Pump?
- L
  Laurie FranklinSep 2, 2025
  A control sensor fault in your Zodiac Heat Pump means the sensor is either defective or disconnected. Replace or reconnect the sensor.
M
Michael CohenSep 4, 2025
What does an anti-frost sensor fault mean on my Zodiac Edenpac 1?
- B
  Bryan RochaSep 4, 2025
  An anti-frost sensor fault on your Zodiac Heat Pump means the sensor is either defective or disconnected. To fix this, replace or reconnect the sensor.
S
Stacey EllisonSep 7, 2025
What does a defrost sensor fault mean on my Zodiac Edenpac 1?
- S
  Samantha WallaceSep 7, 2025
  A defrost sensor fault on your Zodiac Heat Pump indicates that the sensor is either defective or disconnected. Replace or reconnect the sensor.
M
mfisherSep 10, 2025
Why is the anti-frost protection heater on my Zodiac Edenpac 1 Heat Pump activated?
- M
  Mario LopezSep 12, 2025
  The anti-frost protection heater on your Zodiac Heat Pump activates when the outside temperature is too low (below +3°C) and the compressor is OFF. Wait for a natural rise in the outside temperature.
