Zodiac eXO - General List of Functions to Connect

1
EN: WARNING - This product must be serviced by a qualifi ed professional with suffi cient experience in installing and servicing pool equipment to ensure that all
instruc ons given in the product's installa on and user manual are followed to the le er. All safety instruc ons given in the manual must be followed closely to
prevent all risk of injury. Any incorrect installa on and/or improper use shall void the warranty.
EN: WARNING/DANGER - Turn off all switches and the main circuit breaker of the electric circuit for the pool/spa heater before beginning any part
replacement opera on. Failure to comply with these instruc ons may lead to electric shock or cause serious injury or even death. Be careful not to
damage or cause wear to the electrical wiring when connec ng/disconnec ng the wiring in the appliance.
EN: The qualifi ed technician working on the appliance must use/wear personal protec ve equipment (such as safety goggles and
protec ve gloves, etc.) in order to reduce the risk of injury occurring when working on the appliance.
General list of the func ons to be connected
Terminal
block
messages
Type
Cable
clamp
Func ons eXO® (iQ) GenSalt OT
With pH Link or
Dual Link
SENS Input -
Connec on for the control board
for pH Link and Dual Link modules
/ /
PUMP Input -
Connec on for the pH regula on pump
for pH Link and Dual Link modules
/ /
CELL Output 1 Connec on for the electroly c cell
UI Output - Connec on for the display
TEMP Input 3 Connec on for the temperature sensor /
Flow Input 2 Connec on for the fl ow switch
iAL RS485 Input 4 Func on not used – do not wire / / /
VSP RS485 Output 5
Connec on dedicated to controlling the Zodiac®
variable-speed fi lter pump
/
/- Func on not used – do not wire / / /
COVER Input 7
Connec on for the roller shu er/cover for
automa cally managing the LOW func on
SLAVE Output 8
Connec on for an external appliance for the ON/OFF
control of chlorinator (automa c regula on, etc.)
/
AUX 2 12-
24V
Output 9
Connec on dedicated to the ON/OFF control of a
low-voltage device. This connec on does not power
the device: it manages the ON/OFF func on.
AUX 1 230 V Output 10
Connec on dedicated to the ON/OFF control of a
high-voltage device. This connec on does not power
the device: it manages the ON/OFF func on.
/
PUMP 230V Output 11
Connec on dedicated to the power supply to the
pool fi lter pump.
MAINS Input 12
Mains power supply to the appliance
110-240 VAC - 50/60 Hz
: Connec ons made during manufacture : Mandatory connec ons to be made : Func on to be connected (op onal)
