ZODIAC® is a registered trademark of Zodiac Interna onal, S.A.S.U., used under license.
Zodiac Pool Care Europe - Bd de la Romanerie - BP 90023 - 49180 St Barthélémy d’Anjou cedex France - Simplifi ed joint stock company with sole shareholder and a share capital of €1,267,140 / SIREN 395 068 679 / TCR PARIS
www.zodiac.com
Connec ng to an auxiliary device = AUX1 - Dry contact provided for disconnec on from the 230V power supply
(depending on the model)
The chlorinator manages a dry contact calibrated for disconnec on from the 230V power supply. The power supply
is separated with its own protec on (circuit breaker calibrated to suit the equipment controlled or its transformer –
max. 8 A).
Preferred connec on for NL LED spotlights.
Possible controls: ON/OFF with mer for all monochroma c spotlights, ON/OFF/Colour with NL RGBW LED spotlights
230 V contact
All types of auxiliary
device
230 V
Transformer for ligh ng,
booster pump, etc.
maximum 8 A
Preferred connec on for Zodiac® NL LED spotlights
(see installa on manual)
: 230 VAC / 12 VAC
(50/60 Hz) transformer
: Electrical protec on
: Auxiliary relay for
external controller or
switch
With 2 spotlights
With 1 spotlight
Connec on to an auxiliary device = AUX2 - 12- 24V
The eXO® iQ manages a dry contact calibrated for the12 -24V power supply. The power supply is separated with its
own protec on (circuit breaker calibrated to suit the equipment controlled or its transformer – max. 8 A).
Use a relay (not provided) to be able to control a 230 V device.
Possible controls: ON/OFF
12 - 24 V contact
All types of auxiliary
device
12 - 24 V
Transformer for ligh ng,
booster pump, etc.
maximum 8 A
