Zodiac MX8 - I Hydraulic Connections

7
2.3 I Hydraulic connecons
• Turn o the ltraon pump.
• Clean the skimmer basket, the ltraon pump lter basket and the lter if necessary.
2.3.1 Connecon to the sucon line
or
: Hose secon
: Sucon line
: 45° elbow extended (according to model)
: Rotang 45° extended elbow (according to
model)
2.3.2 Connecon to the skimmer
• If the pool has more than one skimmer, connect the pipe to the one which is the closest to the ltraon pump.
: In-ground valve cu
: Flowkeeper valve
: 45° exible elbow
: Hose secon
: Skimmer
Tip: Protect the ltraon system by connecng the owkeeper valve
This valve is used to adjust the ow to opmise the cleaner's performance; it is also very useful for retaining
any debris that may be sucked in and damage the ltraon equipment.
