3.4 I Electricity supply connec ons
• Use of an electrical extension is prohibited when connec ng the control box.
• Make sure that the socket can be easily accessed at all mes and is kept out of rain or splashes.
• The box is splash-proof but must not be immersed. It must not be installed in a fl oodable
area; keep it at least 3.5 metres away from the edge of the pool and avoid exposing it to direct
sunlight.
• Place the control box near the socket.
• Connect the fl oa ng cable into the control box (see image ).
• Push the connector in un l you hear 2 clicks (see image
). Make sure the connector is suffi ciently pushed into place.
If it is not, repeat the opera on.
• Connect the supply cable (see image
). Only connect the control box to a power outlet protected by a 30 mA max-
imum ground fault circuit breaker (if in doubt contact a qualifi ed technician).
• To disconnect the fl oa ng cable from the control box, pinch the 2 clips at the end of the connector and pull at the
same me (see image
).
Tip: box posi oning for be er opera on
Place the control box in the centre of the pool's length, following the safety condi ons rela ng to electrical
connec on.
CLICK
CLICK
