Zodiac Vortex 4 - Immersing the Cleaner; Electrical Connection; Programming the Cleaning Cycles

H0360600.A2.EN Ver.05/2011 4
Dia
g
ram7
2.2.IMMERSINGTHECLEANER



Immersethecleanerinthewater(Diagram71)verticallyandmoveitslightlyinalldirections(72)sothatthe
airintherobotisexpelled.







Itisimperativethatthecleanersinkstothebottomandcomestorestwithoutinterventionfromyou.Spread
thecableoutoverthepool.Foroptimumoperationwerecommendthatyouplacethecaddywiththecontrol
boxmidwaydownthelengthofthepool.






2.3.ELECTRICALCONNECTION

x Placethecontrolboxatadistanceofatleast3.5metersfromthepool
edgeandawayfromdirectsunlight;itcaneitherbeplacedontheground
orattachedtothecaddy.
x Connect the cleaner cable to the control box (Diagram91&92) and
lockthe connectorby firmly tightening thering by turningit clockwise.
Makesuretheconnectorissufficientlypushedintoplace,ifthisisnotthe
caserepeatoperation(92).
x Connect the power cable. Only connect the control box to a power
outletprotectedbya30mAmaximumgroundfaultcircuitbreaker(ifin
doubt contact a qualified electrician). Ensure that the plug is
permanentlyandeasilyaccessible.










2.4.PROGRAMMINGTHECLEANINGCYCLES

2.4.1.Descriptionofkeysandindicatordiodes

ProgramI:Maximisedcleaningofthepoolfloorinminimumtime.Duration1.30hr.
ProgramII:Intensecleaningofthepoolfloorandpoolsides,includingthewaterline.Duration2.30hr.
OFFbutton:usedtocutthecleanerpowersupplyattheendofacleaningcycle.

APPLIESFORVORTEX™4ONLY:
Decreasescleaningtimeby30min .Increasescleaningtimeby1hr 

If you use an extension cable to connect your cleaner to the power supply, ensure the control box is
placednolessthan3.5metersfromthepooledge.
Donotallowbathingwhenthecleanerisinthepool.
Diagram8
Diagram9
