3.4 I Electricity supply connecon
To prevent all risks of electrocuon, re or serious injury, please comply with the following
instrucons:
• Use of an electrical extension is prohibited when connecng the control box.
• Make sure that the socket can be easily accessed at all mes and is protected from rain or
splashes.
• The control box is splash-proof, but must not be immersed in the water or any other liquid.
It must not be installed in a oodable area; keep it at least 3.5 metres away from the edge of
the pool and avoid exposing it to direct sunlight.
• Place the control box near the socket.
• Unscrew the protecve cap (see gure ).
• Connect the oang cable to the control box and lock it in place by turning the ring only in the clockwise direcon (to
prevent damage to the oang cable) (seegure
, ).
• Make sure that the connector is fully pushed in so that no water can get in (see gure ).
• Connect the power cord (see gure ). Only connect the control box to a power outlet protected by a 30 mA maxi-
mum residual current device (if in doubt contact a qualied technician).
Tip: choose the locaon of the control box carefully to prevent the cable from becoming tangled
Place the control box halfway along the length of the pool, in accordance with the safety condions relang
to the electrical connecon. This lets you limit the length of the oang cable to be put into the water to
cover the pool, which simplies set-up and storage operaons.
