5. Work the tyre onto the wheel and verify the rib of the tyre is positioned properly
within the groove of the wheel (Figure 37).
3
Figure 37. Work the Tyre On Around the Wheel
6.
Push and position the rib of the inner side of the tyre in the groove of the wheel
(
Figure 38).
If needed, turn the wheel gently to help with installation.
4
Figure 38. Push the Tyre into Place on the Wheel
Page 31
Zodiac
®
VX65iQ Robotic Pool Cleaner
|
Owner's Manual
