Zodiac VX65 iQ Vortex-Pro - Assembly; Transport Caddy Components

3 Assembly
Contents
The packaging should contain the following items:
• Vortex cleaner and oating cable
• Control unit
• Manual, Quick Start Guide, and Warranty Card
• Transport and storage caddy assembly components (Figure 1)
a. handle frame
b. support blocks (x 2)
c. wheels (x 2)
d. wheel locking clips (x 2)
e. wheel axle / hubcap (x 2)
f. base unit
g. cleaner hook
h. caddy handle
Figure 1. Transport Caddy Assembly Components
x 2
A
B
C
D
x 2
x 2
E
x 2
F
G
H
When unpacking the cleaner and its components:
• Check to make sure each component is in the box.
• Check cleaner and components for damage during transport.
• If there are any missing parts or damage, contact Technical Support at
1300 763 021.
