CAST IRON

CONVERTIBLE JET PUMP

MODEL #1463-0006

Serial Number

Purchase Date

Questions, problems, missing parts? Before returning to your retailer, call our customer service

department at 1-800-584-8089, 7:30 a.m. - 5:00 p.m., EST, Monday - Friday.

ATTACH YOUR RECEIPT HERE

Zoeller

®

is a registered trademark of

Zoeller Co. All Rights Reserved.

IL0194

024990 C

ZoellerAtHome.com

INSTRUCTIONS

FOR DEEP WELL

INSTALLATION

(25-70 FT.)

Table of Contents

Other manuals for Zoeller 1463-0006

Instructions For Deep Well Installation10 pages

Questions and Answers:

E
Emily ScottAug 4, 2025
What to do if my Zoeller 1463-0006 will not start or run?
- P
  paul06Aug 4, 2025
  If your Zoeller Water Pump isn't starting or running, several factors could be at play. First, check the wiring against the motor's wiring diagram. A blown fuse or open circuit breaker can also prevent operation, so replace the fuse or close the breaker. Inspect for loose or broken wiring and tighten connections or replace faulty wiring. A stone or foreign object lodged in the impeller could be the culprit; disassemble the pump to remove any obstructions. In cases of a motor shorting out, replacement is necessary. Lastly, if the thermal overload has opened the circuit, allow the unit to cool before restarting, after identifying the cause of the overload.
M
Mark PayneAug 10, 2025
What to do if Zoeller Water Pump will not deliver water or develop pressure?
- S
  Samantha WatkinsAug 10, 2025
  If your Zoeller Water Pump isn't delivering water or developing pressure, start by ensuring the pump casing is filled with priming water. Check for any leaks in the suction line and repair or replace as needed. Make sure the discharge line is open, allowing priming air to escape. Also, verify the suction line (or valve) is open. A leaking foot valve should be replaced, and a clogged suction screen needs cleaning or replacement.
T
Tina MillerAug 16, 2025
Why is my Zoeller 1463-0006 losing suction?
- N
  nharrisAug 16, 2025
  If your Zoeller Water Pump is experiencing loss of suction, there are several possible causes. Check for air leaks in the suction line and repair or replace any faulty sections. If the suction lift is too high, lower it, install a foot valve, and prime the pump. Insufficient inlet pressure or suction head can also cause this issue; increase inlet pressure by adding more water to the tank or increasing back pressure. Lastly, a clogged foot valve or strainer can restrict flow; unclog it to restore proper suction.
P
Pamela LeeAug 22, 2025
How to fix a Zoeller 1463-0006 Water Pump that vibrates and/or makes excessive noise?
- R
  Robert RitterAug 22, 2025
  If your Zoeller Water Pump is vibrating or making excessive noise, ensure the mounting plate or foundation is rigid enough; reinforce if necessary. Foreign material inside the pump can also cause these issues, so disassemble the pump and clean it thoroughly. A damaged impeller will need replacement, and worn motor bearings should also be replaced to reduce vibration and noise.
T
Tammy UnderwoodAug 28, 2025
How to troubleshoot little or no discharge from Zoeller 1463-0006 Water Pump?
- D
  Derek MartinAug 28, 2025
  If your Zoeller Water Pump has little to no discharge, several issues could be the cause. First, ensure the pump casing is initially filled with water. If the suction lift is too high or long, move the pump closer to the water source. Repair or replace any holes or air leaks in the suction line, using pipe tape and sealing compound. Ensure the foot valve is appropriately sized to match the piping, or install one size larger. The foot valve or suction line should be submerged deeper in the water. Check the motor wiring against the wiring diagram. Replace a leaking casing gasket. Finally, ensure both suction and discharge line valves are open.
