Zoeller 6161 - Electrical Data

3
© Copyright 2017 Zoeller
®
Co. All rights reserved.
Amps
Winding
Resistance
Line-to-Line
Model RPM Voltage Phase Hertz Full Load In Air Shut Off Locked Rotor
N6161 3450 115 1 60 15.5 7.7 52.2 .53/.46*
E6161 3450 230 1 60 7.5 3.6 15.1 4.74/3.88*
I6161 3450 200 1 60 8.8 6.3 19.8 3.59/2.94*
J6161 3450 200 3 60 6.4 3.1 23.6 6.25/5.12
F6161 3450 230 3 60 5.2 2.7 24.0 5.7/4.6
G6161 3450 460 3 60 2.9 1.4 12.0 22.8/18.5
BA6161 3450 575 3 60 2.4 1.3 11.3 38.0/33.0
U6161 2800 220 1 50 5.6 2.6 12.0 4.74/3.88
V6161 2800 220 1 50 5.6 2.6 12.0 4.74/3.88
AK6161 2800 380 3 50 2.0 1.3 10.0 22.8/18.5
V6162 2800 220 1 50 8 3.9 12.0 4.74/3.88
AK6162 2800 380 3 50 3 1.7 10.0 22.8/18.5
N6163 3450 115 1 60 15.0 8.4 52.2 .53/.46*
E6163 3450 230 1 60 7.5 4.0 15.1 4.74/3.88*
I6163 3450 200 1 60 8.5 4.3 19.8 3.59/2.94*
J6163 3450 200 3 60 6.0 3.4 23.6 6.25/5.12
F6163 3450 230 3 60 4.8 3.0 24.0 5.7/4.6
G6163 3450 460 3 60 2.9 1.5 12.0 22.8/18.5
BA6163 3450 575 3 60 2.4 1.5 11.3 38.0/33.0
V6163 2800 220 1 50 6.4 3.1 12.0 4.74/3.88
AK6163 2800 380 3 50 2.9 1.6 10.0 22.8/18.5
E6165 3450 230 1 60 10.2 5.5 20.1 3.06/2.51*
I6165 3450 200 1 60 12.6 6.1 26.8 2.11/1.72*
J6165 3450 200 3 60 7.5 4.1 31.1 3.74/3.06
F6165 3450 230 3 60 7.4 3.8 29.8 5.7/4.5
G6165 3450 460 3 60 3.7 2.1 14.9 22.6/18.2
BA6165 3450 575 3 60 3.0 1.7 10.0 38.8/34.5
V6165 2800 220 1 50 9.6 5.5 20.0 3.06/2.51
AK6165 2800 380 3 50 2 1.1 8.0 22.6/18.2
E6185 3450 230 1 60 9.8 5.0 20.1 3.06/2.51*
I6185 3450 200 1 60 11.5 5.1 26.8 2.11/1.72*
J6185 3450 200 3 60 7.5 3.6 31.1 3.74/3.06
F185 3450 230 3 60 7.4 3.8 29.8 5.7/4.5
G6185 3450 460 3 60 3.7 1.9 14.9 22.6/18.2
BA6185 3450 575 3 60 3.3 1.3 10.0 38.8/34.5
V6185 2800 220 1 50 10 3.9 20.0 3.06/2.51
AK6185 2800 380 3 50 4.1 1.9 17.0 13.9/11.3
E6186 3450 230 1 60 13.7 9.3 45.7 1.29/1.05*
I6186 3450 200 1 60 17.2 11.8 54.5 .86/.71*
J6186 3450 200 3 60 10.3 6.0 45.2 2.62/2.14
F186 3450 230 3 60 9.2 5.5 39.4 3.52/2.8
G6186 3450 460 3 60 4.6 2.8 19.7 13.9/11.3
E6188 3450 230 1 60 14.0 7.4
45.7 1.29/1.05*
I6188 3450 200 1 60 16.8 9.8 54.5 .86/.71*
J6188 3450 200 3 60 10.3 4.7 45.2 2.62/2.14
F6188 3450 230 3 60 8.9 4.1 39.4 3.52/2.8
G6188 3450 460 3 60 4.6 2.0 19.7 13.9/11.3
BA6188 3450 575 3 60 3.5 1.6 15.9 20.6/18.3
E6189 3450 230 1 60 17.1 9.4 45.7 1.29/1.05*
I6189 3450 200 1 60 20.5 11.5 54.5 .86/.71*
J6189 3450 200 3 60 13.2 5.9 45.2 2.62/2.14
F6189 3450 230 3 60 11.2 5.1 39.4 3.5/2.8
G6189 3450 460 3 60 6.0 2.8 19.7 13.9/11.3
BA6189 3450 575 3 60 5.8 2.1 15.9 20.6/18.3
V6189 2800 220 1 50 14.2 11.2 40.0 1.29/1.05
AK6189 2800 380 3 50 4.5 2.2 15.0 13.9/11.3
N6282 1725 115 1 60 10.3 7.3 30.2 1.46/1.20*
E6282 1725 230 1 60 5.0 4.0 15.1 5.84/4.80*
I6282 1725 200 1 60 6.1 4.5 17.7 4.65/4.05*
J6282 1725 200 3 60 3.6 2.5 12.8 8.13/6.62
F6282 1725 230 3 60 3.0 2.3 12.2 9.6/7.9
G6282 1725 460 3 60 1.7 1.1 6.1 38.4/31.5
BA6282 1725 575 3 60 1.4 1.1 5.11 63.6/55.3
V6282 1400 220 1 50 5.7 5.1 17.0 5.84/4.8
AK6282 1400 380 3 50 1.6 1.2 6.0 38.4/31.5
E6284 1725 230 1 60 8.9 6.7 24.9 2.62/2.14*
I6284 1725 200 1 60 9.3 6.4 26.8 2.01/1.82*
J6284 1725 200 3 60 5.5 4.0 26.3 2.99/2.70
F6284 1725 230 3 60 5.0 3.5 22.2 4.8/4.4
G6284 1725 460 3 60 2.6 1.9 11.1 19.2/17.4
BA6284 1725 575 3 60 2.2 1.7 12.1 20.4/17.7
N6292 3450 115 1 60 15.0 10.6 52.2 .53/.46*
E6292 3450 230 1 60 7.5 4.7 52.2 4.74/3.88*
I6292 3450 200 1 60 8.8 7.4 19.8 3.59/2.94*
Electrical Data
CONTINUED ON NEXT PAGE
* Line to line reading will only reect the run winding resistance.
Start winding resistance can only be measured after removing the cover.
