Manual Self-Test
9650-0308-01 Rev. A ZOLL AED Plus Service Manual 1–9
3.0 Manual Self-Test
Use this test to initiate the unit’s self-diagnostic procedure, which verifies the following:
• Battery usage since last reset.
• Defibrillation electrodes are properly connected.
• ECG signal acquisition and processing circuitry is functional.
• Defibrillator charge and discharge circuitry (operational at 2 joules) is functional.
• Microprocessor hardware and software are functional.
• CPR monitoring circuitry and compression depth sensor are functional (when CPR-D•padz
are attached).
• Audio output circuitry is functional.
• Display screen (if present) is functional.
Tools Needed
• None.
Test Setup
• Turn off the AED Plus unit.
• If they are not already in place, preconnect defibrillation electrodes to the unit.
Test Procedure
Test Action Expected Result(s) Pass Fail
3.1 Press and hold the ON/OFF
button for at least 5 seconds.
• Within 10 seconds after the unit is
turned on, the Status indicator
displays a green check.
• On the top panel, the indicator
lights for the rescue actions
illuminate in sequence.
! UNIT OK
!!
If an IrDA connection is established, turn off the unit;
otherwise, the unit shuts down automatically.
