AED Plus Error Log Messages
9650-0308-01 Rev. A ZOLL AED Plus Service Manual 2–5
14 Patient impedance experienced a short
15 The A2D is getting non-accurate readings during its test
17 The message queue overflowed
18 PowerOn task has timed out while waiting for a self test result to come back.
19 Calibration faults that occur during a clinical event.
20 An unexpected error has occurred when calling a Nucleus operation.
21 An unexpected error has occurred when calling a Rhapsody operation.
22 An unexpected coding error has occurred.
23 No Language installed - corrupt language.
24 The shock button is pressed/stuck.
25 The ECG Calibration data is invalid
26 The Patient Impedance Calibration data is invalid
27 A critical flash error has occurred
28 The WatchDog is not enabled during clinical event
29 The clock test failed
Note: Error numbers 256 and greater indicate noncritical conditions.
Table 2-2. AED Plus Error Log Messages (continued)
Error
No.
Error Message
