3. Press and hold mounting position for 10 seconds to assure good adhesion.
GPS System Check
At a minimum, the installer must perform a system check to verify proper installation. If at all
possible a full and complete checkout using Zonar’s Ground Traffic Control® website should
be performed. Not all installers will have access to this area; check with a Zonar Customer
Service representative if in doubt. This procedure covers the minimum requirements for a
system installer.
Check the LEDs
Turn the key on, and with the engine running check the LEDs on the GPS unit within 2
minutes. They should display the following sequence after everything is connected.
LED
Condition
CELLULAR
Solid green. If blinking, ensure unit is an area with cellular coverage.
GPS
Solid green or orange. If blinking, the GPS is acquiring satellites (antenna
must have a clear view to sky). Do not proceed further until GPS LED is
solid.
STATUS
Solid green. If blinking, check the cables at the GPS unit and the vehicle
connector. Also check the integrated 4 Pin power pigtail at the GPS unit. If
the cables and the 4 Pin power pigtail are good, use a standalone 4 Pin
power cable.
Note: STATUS will blink fast red when power is removed and the device is
operating on internal backup power.
Note: STATUS will blink blue upon startup If Bluetooth is enabled while
the device is in pairing mode.
DATALINK1
•
Single
green
blink per second if J1708/J1587 data is present.
• Single green blink per second if good communication between the
Light Duty cable and the GPS device.
• Single red blink per second if no ECM connection or if ECM
connection not working properly.
DATALINK2
•
Single
green
blink per second if J1939 data is present.
• Single green blink per second if good communication between the
Light Duty cable and the GPS device.
• Single red blink per second if no ECM connection or if ECM
connection not working properly.
