Specifications:
Standards
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b standards
OS Windows 2000, XP, Vista, 7; Linux
User interface Easy to use user configuration software
Transmit distance
Indoor up to 100m ; Outdoor up to 400m
(limited to environment)
roaming
Support multipoint auto roaming and configuration;
Support wireless network environments auto detect.
LED LAN 1-4/WAN/WLAN/WPS/SYS/POWER
Antenna type One detachable antenna
Frequency range 2.4GHz ~ 2.4835GHZ
Radio data rate
11n: 150/130/117/104/78/52/39/26/13Mbps
65/58.5/52/39/26/19.5/13/6.5Mbps
11g: 54/48/36/24/18/12/9/6Mbps
11b: 11/5.5/2/1Mbps
Modulation
OFDM, CCK, BPSK, QPSK
Spectrum Spread Technology
DSSS
Sensitivity
11n 20MHz/40MHz: -65dBm
54Mbps: -72dBm
11Mbps: -88dBm
Antenna Gain 3dBi
Transmission Rate 17dBm
Power 9V 1A
Max. Consumption 6W
Flash 2M Bytes
System Memory 16M Bytes
MAC Address Entry 1K
Channels
11 Channels (USA, Canada) ; 13 Channels (Europe)
Media Access Protocol
WMM
Data security WPA/WPA2; 64/128-bit WEP; TKIP/AES
Operation Temp.
0ºC ~ 40ºC
Storage Temp.
-20ºC ~ 70ºC
Operation Humidity
10%~90% RH no condensing
Operation Humidity
5%~90% RH no condensing
Dimension (L x W x H)
160mm x 102mm x 33mm
Weight
205g
