Zoom B9.1ut User Manual

B9.1ut Top Panel
B9.1ut Rear Panel
6
ZOOM B9.1ut
Controls and Functions
PATCH/BANK [
▼
]/[▲] foot
switches
Function foot switches 1 – 3
Foot switches 1 – 4
OUTPUT GAIN (-10dB/0dB) switch
INPUT jack
GROUND switch
PRE/POST switch
BALANCED OUT R connector
BALANCED OUT L/MONO connector
OUTPUT R jack
OUTPUT L/MONO jack
PHONES jack
EXT LOOP SEND jack
EXT LOOP RETURN jack
MIDI OUT connector
MIDI IN connector
EXT LOOP GAIN
(-10dBm/+4dBm) switch
LEVEL knob
CONTROL IN jack DC IN jack
USB port
POWER switch
AUX IN jack
◆ Control section (see next page)
◆ Accelerator section (see next page)
◆ Pre-amp section (see next page)
[VOLUME PEDAL]
LED (see page 33)
Expression pedal
0804B9E.indb60804B9E.indb6 08.4.2510:57:16AM08.4.2510:57:16AM
