ZOOM G1/G1X
6
Selecting a Patch
A0
HINT
Turn power on
Set the G1/G1X to play
mode
When using the G1/G1X on batteries, plug a
shielded cable with mono phone plug into the
[INPUT] jack on the rear panel of the G1/G1X.
When using the G1/G1X with the AC
adapter, plug the adapter into the outlet
and plug the cable from the adapter into
the [DC IN] jack on the G1/G1X.
If the Module selector is set to a position
other than "PLAY", set it to "PLAY".
The currently selected
bank and patch
number are shown on
the display.
Select a patch
To switch the patch, press one of the [W]/[Q] foot switches.
Pressing the [W] foot switch calls up the next lower patch, and pressing the [Q] foot
switch calls up the next higher patch.
Repeatedly pressing one foot switch cycles through patches in the order A0 – A9 ... d0 – d9
→ 00 – 09 ... 30 – 39 → A0, or the reverse order.
Immediately after turning the G1/G1X
on, the unit will be in play mode, even if
the Module selector is set to a position
other than "PLAY".
Turn the guitar amplifier on and adjust
the volume to a suitable position.
Bank name Patch number
To try out the various effects of the G1/G1X, we recommend that you simply play your instrument while
switching patches.
Selecting a Patch
ZOOM G1/G1X
7
80
Adjust the master level
To adjust the master level in play mode,
you can use the [VALUE] knob.
When you turn the [VALUE] knob, the master
level setting is shown for a time on the display.
The master level setting range is 0 – 98, 1.0.
It will be reset to 80 when the unit is turned off
and then on again.
NOTE
When using headphones, this knob
adjusts the listening volume.
Directly selecting a bank
To select the banks A - d, 0 - 3 directly, use the [BANK UP•TAP]
key.
Each push of the key switches to the next higher bank.
NOTE
With the G1, using the foot switch (FS01) to switch banks is also
possible (→ p. 16).
