Zoom H1 User Manual

10
.
2.
While pressing , slide the power switch to start the
unit in version upgrade mode.
The version currently used by
the unit and the upgrade ver-
sion are shown on the screen
alternately.
3.
If the version upgrade shown is the one desired, press the
again
to start the upgrade.
MEMO
unit is starting up. Version 1.00 is shown
as “1/00,” for example.
1.
•
from our web site (www.zoom.co.jp).

Zoom H1 Specifications

General

Recording Format	WAV, MP3
Max Sound Pressure Level	120 dB SPL
Battery Life	Up to 10 hours
Simultaneous Recording Tracks	2
Sample Rate	44.1 kHz, 48 kHz, 96 kHz
Connectivity	USB 2.0
Input	3.5mm stereo mini-jack
Output	3.5mm stereo mini-jack
Power Supply	1x AA battery or USB power
Weight	60 g (without battery)
Bit Depth	16-bit/24-bit
Recording Media	microSD/microSDHC card
Frequency Response	20 Hz to 20 kHz
Dimensions	44 mm (W) x 136 mm (D) x 31 mm (H)
