Zoom H1 User Manual

1
Prepare
Turning the power on/off
Turning the unit ON and OFF is easy.
1.
To turn the unit ON, slide the power
switch down for about 1 second.
The buttons can be disabled to prevent recording from
being stopped accidentally, for example.
1.
To disable the buttons, slide the
power switch upward to HOLD.
2.
To enable use of the buttons again,
slide the power switch back to the
middle position.
Prepare
Disabling the buttons
2.
To turn the unit OFF, slide the
power switch down for about 1
second again.
↓
↑

Zoom H1 Specifications

General

Recording Format	WAV, MP3
Max Sound Pressure Level	120 dB SPL
Battery Life	Up to 10 hours
Simultaneous Recording Tracks	2
Sample Rate	44.1 kHz, 48 kHz, 96 kHz
Connectivity	USB 2.0
Input	3.5mm stereo mini-jack
Output	3.5mm stereo mini-jack
Power Supply	1x AA battery or USB power
Weight	60 g (without battery)
Bit Depth	16-bit/24-bit
Recording Media	microSD/microSDHC card
Frequency Response	20 Hz to 20 kHz
Dimensions	44 mm (W) x 136 mm (D) x 31 mm (H)
