Zoom H1 User Manual

Connecting with a computer <Supplement>
New
function
in Ver.2
Connect
2.
<To use as a MicroSD card reader>
Press while “CArd” is displayed.
<To use as an audio interface>
Press while “AUdIo” is displayed.
1.
With the power off, connect this unit to a Windows PC or a Macintosh us-
ing a USB cable.
3.
<When “CArd” is selected>
It starts working as a MicroSD card reader.
<When “AUdIo” is selected>
When the screen to select the sampling frequency appears,
use / to select the frequency and press
.
4.
It starts working as an audio interface.
This unit’s input signal is sent to the com-
puter, and you can use this unit to moni-
tor the playback signal on the computer.
Displayed alternately at
one-second interval
/
Input/output level
4
1 Adjusts the output level
2 Switches on/off the LO CUT function
3 Switches on/off the AUTO level function
4 Adjusts the input level
5 Disables the keys
6 The playback signal of the computer can be monitored
when line/headphone output jack is not used.
5
6
2 3
1
Blink
Blink
MEMO
If no action is performed for 10 seconds, it will automatically
start working as a MicroSD card reader.
MEMO
The sampling frequency should be set to the same value
as the recording software and playback files.

Zoom H1 Specifications

General

Recording Format	WAV, MP3
Max Sound Pressure Level	120 dB SPL
Battery Life	Up to 10 hours
Simultaneous Recording Tracks	2
Sample Rate	44.1 kHz, 48 kHz, 96 kHz
Connectivity	USB 2.0
Input	3.5mm stereo mini-jack
Output	3.5mm stereo mini-jack
Power Supply	1x AA battery or USB power
Weight	60 g (without battery)
Bit Depth	16-bit/24-bit
Recording Media	microSD/microSDHC card
Frequency Response	20 Hz to 20 kHz
Dimensions	44 mm (W) x 136 mm (D) x 31 mm (H)
