Crane Operation
Operator’s Manual for Crawler Crane
is fitted with main boom and fixed jib.
If wind speed reaches or exceeds these values, the entire boom should be lowered
down.
b) Right control panel
1. Illumination
Press the switch (44), the interior light in the cab will light up.
Turn the master lighting switch to the 1st position or the 2nd position, the LED
on the switches of the control panel will light up.
Press the switch , working floodlight on slewing table will light up.
Before switching on the working floodlight switch , put the master lighting
switch
on the 2
nd
position.
2. Windshield wiper and washer
Turn on front windshield wiper and roof windshield wiper by pressing the front
windshield wiper switch and roof windshield wiper switch respectively.
When front windshield needs to be washed, please press the “front windshield
washer” switch .
3. Fan
There is a fan fitted on the rear right side of the operator’s cab. Turn on the switch, the
fan will run.
4. Horn
Check if the horn is working properly with foot-operated switch before work.
The horn must be actuated before starting the engine to warn the person in the
vicinity of the crane.
4-24
