AMD RS880 motherboard
Expansion Slots
The
motherb
oard
contain
s t
wo
expa
nsion
s
lots:
o
ne
PCI
Express x1 slot and
one Mini
PCIE slot.
Mini PCIE Slot-MINI_PCIE1
There is one Mini PCIE slot, reserved for the WiFi Module.
PCIE x1 Slot-PCIEX1
There
is
one
PCI
Express
x1
slot
that
is
designed
to
accommodate
less
bandwidth
intensive cards, such as a modem or LAN card.
