Zotac ZBOX User Manual

ZOTAC ZBOX
2
Table of Contents
Product specications ------------------------------------------------------------------------------------------- 3
Safety information ------------------------------------------------------------------------------------------------- 4
Setting up your system ---------------------------------------------------------------------------------------- 4
Care during use ------------------------------------------------------------------------------------------------- 4
Welcome --------------------------------------------------------------------------------------------------------------5
Package contents ---------------------------------------------------------------------------------------------- 5
Getting to know your ZOTAC ZBOX -------------------------------------------------------------------------6
Front view -------------------------------------------------------------------------------------------------------- 6
Rear view --------------------------------------------------------------------------------------------------------- 7
BIOS settings of specic functions -------------------------------------------------------------------------- 8
How to disable the ring LED indicator --------------------------------------------------------------------- 8
How to disable the integrated IR receiver ---------------------------------------------------------------- 10
Installing hardware inside the ZOTAC ZBOX -------------------------------------------------------------12
Installing a memory module --------------------------------------------------------------------------------- 13
Removing a memory module -------------------------------------------------------------------------------- 14
Installing a hard disk drive ----------------------------------------------------------------------------------- 15
Installing an M.2 SSD ----------------------------------------------------------------------------------------- 17
Setting up your ZOTAC ZBOX ---------------------------------------------------------------------------------19
Positioning your ZOTAC ZBOX --------------------------------------------------------------------------------21
Installing the stand --------------------------------------------------------------------------------------------- 21
Attaching your ZOTAC ZBOX to a monitor --------------------------------------------------------------22
Installing drivers and software -------------------------------------------------------------------------------- 23
Installing an operating system ------------------------------------------------------------------------------ 23
Installing system drivers -------------------------------------------------------------------------------------- 23
Using your ZOTAC ZBOX ----------------------------------------------------------------------------------------24
Conguring a wireless connection ------------------------------------------------------------------------- 24
Conguring a wired connection ----------------------------------------------------------------------------- 25
Using a static IP --------------------------------------------------------------------------------------------25
Using a dynamic IP (PPPoE connection) ------------------------------------------------------------25
Conguring audio output ------------------------------------------------------------------------------------- 26
Installing Windows 7 ---------------------------------------------------------------------------------------------- 27
Intel Rapid Storage Technology -------------------------------------------------------------------------------30
Introduction ------------------------------------------------------------------------------------------------------30
Setting up Intel Rapid Storage Technology --------------------------------------------------------------30

Zotac ZBOX Specifications

General

Processor cache	2 MB
Processor cores	2
Processor model	E-350
Processor family	AMD E
Processor cache type	L2
Processor manufacturer	AMD
Number of processors installed	1
Product type	Mini PC
Motherboard chipset	AMD M1
Memory slots	2x SO-DIMM
Internal memory	2 GB
Memory clock speed	1066 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	1 x 2 GB
HDD speed	5400 RPM
Optical drive type	Blu-Ray DVD Combo
Card reader integrated	Yes
Total storage capacity	250 GB
Compatible memory cards	Memory Stick (MS), MMC, MS PRO, SD, SDHC, xD
CD read speed	24 x
Networking features	Gigabit Ethernet
Discrete graphics card model	-
On-board graphics card model	AMD Radeon HD 6310
On-board graphics card family	AMD Radeon HD 6000
Display included	No
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Wi-Fi standards	Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Product color	Black, Silver

Weight and Dimensions

Depth	40 mm
Width	280 mm
Height	187 mm
