Zotac ZBOX User Manual

ZOTAC ZBOX
3
Product specications
q Chipset
v Intel H170 chipset
q Microprocessor support
v Intel Core i7-6700T, quad core 2.8 GHz (8 M Cache, up to 3.6 GHz) for ZBOX-MI571 series
v Intel Core i5-6400T, quad core 2.2 GHz (6 M Cache, up to 2.8 GHz) for ZBOX-MI551 series
q Operating systems:
v Supports Windows 7 / 8.1 / 10 32/64-bit
q System Memory support
v Two DDR3L-1600/1333 SODIMM slots
v Up to 16 GB of memory
q USB Ports
v One USB 3.1 Type-C port, one USB 3.1 port (from SD/USB 3.1 Combo)
v Two USB 3.0 ports, one USB 2.0 port
q Onboard Serial ATA
v SATA 6.0 Gb/s transfer rates
v Supports one 2.5-inch SATA HDD or SSD (max 9.5mm height)
q Expansion slot
v One M.2 SATA SSD slot (22/42,22/60,22/80)
q Onboard Dual LAN
v Supports 10/100/1000 Mbps operation
v Supports IEEE 802.3
q WiFi/Bluetooth support
v 802.11ac (dual-band)
v Bluetooth v4.0
q Onboard Audio
v Stereo analog audio output and Microphone input
q Onboard Graphics support
v Intel HD Graphics 530
v DP 1.2: (max resolution: 3840x2160 @60Hz)
v HDMI 1.4: (max resolution: 4096x2160 @24Hz)
q Product Size
v 188mm x 188mm x 51mm

Zotac ZBOX Specifications

General

Processor cache	2 MB
Processor cores	2
Processor model	E-350
Processor family	AMD E
Processor cache type	L2
Processor manufacturer	AMD
Number of processors installed	1
Product type	Mini PC
Motherboard chipset	AMD M1
Memory slots	2x SO-DIMM
Internal memory	2 GB
Memory clock speed	1066 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	1 x 2 GB
HDD speed	5400 RPM
Optical drive type	Blu-Ray DVD Combo
Card reader integrated	Yes
Total storage capacity	250 GB
Compatible memory cards	Memory Stick (MS), MMC, MS PRO, SD, SDHC, xD
CD read speed	24 x
Networking features	Gigabit Ethernet
Discrete graphics card model	-
On-board graphics card model	AMD Radeon HD 6310
On-board graphics card family	AMD Radeon HD 6000
Display included	No
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Wi-Fi standards	Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Product color	Black, Silver

Weight and Dimensions

Depth	40 mm
Width	280 mm
Height	187 mm
