Zotac ZBOX User Manual

ZOTAC ZBOX
23
Installing drivers and software
Installing an operating system
The ZOTAC ZBOX does not ship with an operating system preinstalled. The user must install
the operating system before the ZOTAC ZBOX can be used. The following operating systems
are supported:
• Windows 7 / 8.1 / 10 32/64-bit
Follow the instructions below to install an operating system:
1. Attach external DVD drive via USB 3.0 or 2.0 ports.
Note: USB 3.1 port / USB 3.1 Type-C port does not support OS installation.
2. Insert disk for operating system (Windows or Linux).
3. Wait for the ZOTAC ZBOX to boot from the disk.
4. Follow the onscreen directions to install the operating system.
5. Install system drivers to gain full functionality of the ZOTAC ZBOX hardware and features.
Installing system drivers
Before you can use the full features of the ZOTAC ZBOX, the system drivers must be installed.
The following types of operating systems are supported by the ZOTAC ZBOX driver DVD and
USB ash drive:
• Windows 7 / 8.1 / 10 32/64-bit
Follow the instructions below to install the system drivers:
1. Insert the ZOTAC ZBOX driver DVD or driver USB ash drive. If autorun is enabled, the
driver installation main menu will show up automatically. If autorun is disabled, you may
click the le Launch.EXE to bring up the driver installation main menu.
2. The following drivers are available on the DVD and USB ash drive:
• Intel Chipset Driver
• HDA Sound Driver
• Intel Graphics Driver
• Ethernet PCI-E Driver
• Wireless Network Driver
• Intel Management Engine

Zotac ZBOX Specifications

General

Processor cache	2 MB
Processor cores	2
Processor model	E-350
Processor family	AMD E
Processor cache type	L2
Processor manufacturer	AMD
Number of processors installed	1
Product type	Mini PC
Motherboard chipset	AMD M1
Memory slots	2x SO-DIMM
Internal memory	2 GB
Memory clock speed	1066 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	1 x 2 GB
HDD speed	5400 RPM
Optical drive type	Blu-Ray DVD Combo
Card reader integrated	Yes
Total storage capacity	250 GB
Compatible memory cards	Memory Stick (MS), MMC, MS PRO, SD, SDHC, xD
CD read speed	24 x
Networking features	Gigabit Ethernet
Discrete graphics card model	-
On-board graphics card model	AMD Radeon HD 6310
On-board graphics card family	AMD Radeon HD 6000
Display included	No
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Wi-Fi standards	Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Product color	Black, Silver

Weight and Dimensions

Depth	40 mm
Width	280 mm
Height	187 mm
