3.Using Install Helper Application to Detect Position
Before installingthe MC7010CA, you can install the Install Helper applicationon your mobile phone
and connect to the device to detect the signal strength and help you detect and locate the installation
location.
NOTE:
View the label on this guide to get the link or QR cord to download the Install Helper application.
Powering on the MC7010CA
1. Connect the CAT5Enetwork cable which is from the MC7010CA to the network port(RJ45-2) on
the POE adapter.
2. Connect the power connector on the POE adapter to the socket.
Connecting to the MC7010CA
Before connecting to the device, make sure that you have installed the Install Helper application and
turn Bluetooth
®
on of your phone.
1. Open the app list and touchInstall Helper.
2. Touch CONNECT TO DEVICE and select MC7010CA.The Bluetooth of the device will turn on
automatically, and your phone automatically scans for and displays the IDs of all available
Bluetooth devices in range.
3. Touch the device you want to pair with.
4. Touch PAIR& CONNECT >PAIRto accept the connection.
5. Enter the password and touch OK to manage the device.
NOTE:
View the label onthis guideto get the default password.
Detecting and AdjustingInstallation Position
1. Move the device around the mounting wall/pole or try different positions and touch DETECT
POSITION.
2. Follow the on-screen instructions to attach the device to your target position, and slowly move it
until it provides feedback.
NOTE:
The device does not support elevation angle adjustment. It only supports horizontal 180°
adjustment.
3. The signal strength at the current position is displayed(Perfect, Great, Good, Poor and
