Frequency(Channel): Choose the appropriate channel to
optimize the performance and coverage of your wireless network.
WDS Mode: WDS enable router to communicate with other APs,
WDS connection is two-way communication, APs should know
each others wireless MAC address. And make sure that all APs
share the same SSID and channel.
WDS configuration is shown below:
1.Set the same SSID
and channel for APs
Manually set the SSID and channel is
strongly recommended
2.Select WDS mode：
Disable, Lazy Mode,
Bridge Mode or
Repeater Mode
·If you select Disable, WDS is
disabled.
·If you select Lazy Mode，WDS is
enabled, and set wireless MAC
address only on the peer APs.
·If you select Bridge Mode, WDS is
enabled, and set the peer APs wireless
MAC address on router.
·If you select Repeater Mode, WDS is
enabled, and set the peer APs wireless
MAC address on router.
3.Select Phy mode:
CCK,OFDM,HTMIX or
GREENFIELD
4.Select Encryp
Type:
WEP，TKIP，AES
If you select NONE, all the data
transmitted without encryption, and
other station can access router.
5.Set peer AP's
wireless MAC address
on router
Only Repeater Mode and Bridge
Mode need this。
The HT physical Mode parameters are shown below:
Operating Mode: In Mixed Mode, packets are transmitted with a
preamble compatible with the legacy 802.11a/g, the rest of the
packet has a new format. In Green Field, high throughput
packets are transmitted without a legacy compatible part.
Channel Bandwidth: Set the HT physical channel bandwidth.
Guard Interval: Guard interval is to introduce immunity to
propagation delays, echoes and reflections, to which digital data
