Zte ZXA10 C300 Installation Guide

AppendixA
IndoorCabinetGrounding
SystemConnection
TableofContents
ŸOverview................................................................................................................A-1
ŸCentralOfceCabinetGrounding...........................................................................
A-1
A.1Overview
Groundingensuressecurerunningandprotectionforthesystem.Groundingprovides
theequipmentwiththecapabilityofanti-electromagneticinterference,preventingthe
equipmentfromdamagecausedbylightning.
Beforeconnectingthecabinettothegroundingnetwork,makesurethefollowingitemsare
ready:
lTheequipmentroomlightningprotectiondevicesareavailable.
lTheequipmentroomgroundingdevicesareinstalled.
lToolsforcableinstallationareinplace.
lAllthegroundingcablesandinter-cabinetcablesareplacedaccordingtothelayout
oftheindoorcabinet.
A.2CentralOfceCabinetGrounding
Thistopicincludesthefollowing:
lCentralOfceCabinetGrounding
lRemoteOfceCabinetGrounding
A.2.1CentralOfficeCabinetGrounding
Therearetwotypesforconnectingthecentralofcecabinettothegroundingnetwork:
lType1
lType2
Type1
lCabinetgrounding
1.ConnecttheGNDP ,-48VGND,GND,andcabinetgroundingcablesfromthe
busbartothehorizontalgroundingbar.
A-1
SJ-20110909101511-005|2011-12-31(R1.1)ZTEProprietaryandCondential

Zte ZXA10 C300 Specifications

General

Model	ZXA10 C300
Manufacturer	ZTE
Humidity	5% to 95% (non-condensing)
Uplink Ports	2 x 10GE
Supported Standards	IEEE 802.3ah, ITU-T G.984.x
GPON Ports per card	8
EPON Ports per card	8
Ports	GPON/EPON ports
Storage Temperature	-40°C to +70°C
Dimensions	482.6 mm
