Zte ZXR10 5900E Series - _ Topology

All Rights reserved, No Spreading abroad without Permission of ZTE
7
D. IP source check Configuration Procedure
_ Topology
DHCP server
Inlegal host
IP:10.1.1.15
1
2
Legal host
IP:10.1.1.15
Discard
3
_ Setup
Step1:Enable DHCP snooping function same as Case A
Step2: Enable IP Souce guard on port
ZXR10(config-gei_1/2)#ip dhcp snooping ip-source-guard ip-base
E. Static user binding Configuration Procedure
_ Topology
DHCP server
No defined static user
1
2
Static user
Discard
3
_ Setup
Step1：Enable DHCP snooping function same as case A.
Step2: Enable IP Souce guard on port
ZXR10(config-gei_1/2)#ip dhcp snnoping ip-source-guard mac-ip-base
Step3: Configure Static user binding table entry on vlan
