Zte ZXR10 8900 Series - _ Topology; Test Instruction for Zxr

All Rights reserved, No Spreading abroad without Permission of ZTE
9
_ Setup
Step1：configure ACL
ZXR10(config)#acl standard number 10
ZXR10(config-std-acl)#rule 1 deny 192.168.1.100 0.0.0.0
Step2：enable ACL on port inbind
ZXR10 (config-fei_1/2)#ip access-group 1 in
Test Instruction for ZXR10 8900
A.DHCP Snooping Configuration Procedure
_ Topology
DHCP server
Fake server
1
2
3
DHCP Ack
DHCP Require
X
_ Setup
Step1: configure vlan
ZXR10(config)#interface gei_1/1
ZXR10(config)#ipv4 protocol-protect mode dhcp enable
ZXR10(config-gei_1/1)#switch access vlan 100
