P-320W User’s Guide

Chapter 7 DHCP Server 95

CHAPTER 7

DHCP Server

7.1 DHCP

DHCP (Dynamic Host Configuration Protocol, RFC 2131 and RFC 2132) allows individual

clients to obtain TCP/IP configuration at start-up from a server. You can configure the Prestige

as a DHCP server or disable it. When configured as a server, the Prestige provides the TCP/IP

configuration for the clients. If DHCP service is disabled, you must have another DHCP server

on your LAN, or else the computer must be manually configured.

7.2 DHCP Screen

Click the DHCP Server link under Network and the General tab. The following screen

displays.

Figure 51 General
