MANUGENH3 0N3
User manual
VER 1.05
2.6.1
Cabling: H3 to Cable Splitter or Connection Box
Open connection to cable splitter
User must connect cable wires to the terminal J1. For a correct cabling please refer to the following
table:
VERSION
RS-422
Wire Connection
Cable Splitter J1
Shield
1
Y
ellow
2
Green
3
Pink
4
Grey
5
Y
ellow/Brown
6
Y
ellow/White
7
Grey/Brown
8
White/Green
9
Brown/Green
10
White/Grey
11
White/Pink
12
Blu
13
Red/Blu
14
Red
15
Purple
16
Black
17
Grey/Pink
18
White
19
Brown
20
35
37
Table of Contents
Table of Contents
3
Acronyms
5
General Information
6
Manual Organization
6
Organization of Safety Notices
6
Safety Guidelines
6
Responsibilities
6
Intended Use
8
Protection against Electrostatic Discharges
8
Transport and Storage
8
Installation
8
Operation Main Facts
9
Supply Voltage
9
Emergency Stop Push-Button
9
Enabling Device
10
State Selector
11
Environmentally-Friendly Disposal
12
Disposal
12
Technical Data
13
Introduction
13
Selection Guide
15
Product Coding
16
System Overview
17
H3 Terminal Overview
17
Ergonomics
18
Housing
18
Operating and Display Field
18
Electronics
18
Input Devices
19
Override Potentiometers
19
Handwheel (Optional)
19
Rubber Keypad
19
Interfaces to NC/PLC
20
USB Interface
20
Touch Screen Pen
21
Safety Related Devices
21
Cable Splitter and Connection Box Overview
22
Dimensions
23
Terminal
23
Cable Splitter, Connection Box
24
Technical Data Details
25
Handheld Terminal Specifications
25
State Selector (Common)
26
Handheld Terminal Chemical Resistance
27
Test Results
28
Cable Connections
29
State Selector (Bit 0)
29
State Selector (Bit 1)
29
State Selector (Bit 2)
29
State Selector (Bit 3)
29
2.5.3 Cable Connector Specifications and Pin-Out
30
Cable Connector Specifications and Pin-Out
30
DB25 Connector Pin-Out
30
Enabling Device C1 Contact (Normally Open)
30
Enabling Device C1O Contact (Normally Open)
30
Enabling Device C2 Contact (Normally Open)
30
Enabling Device C2O Contact (Normally Open)
30
Circular Connector
31
Emergency Stop Button
32
Enabling Device
32
Safety-Related Devices
32
State Selector
32
Detail on the PL and SIL Level of the Safety Related Functions
33
Cable Splitter Cabling Scheme
35
Cabling: H3 to Cable Splitter or Connection Box
36
Cabling: Cable Splitter or Connection Box to CN/PLC
38
EC Directives
39
International Safety Standards
39
Standards
39
