2N EasyGate User Manual

27
11. Technical Parameters
GSM:
GSM module, GSM bandwidth
MC39i EGSM 900 / GSM 1800
MC45 EGSM 900 / GSM 1800 / GSM 1900
MC46 EGSM 850 / GSM 1800 / GSM 1900
Transmission power
2 W EGSM 850 / 900 MHz,
1W GSM 1800 / 1900 MHz
Receiver sensitivity -105 dBm
Audio
HR+FR+EFR Half rate+Full rate+Enhanced full rate
Echo cancellation, Echo suppression
DATA
GPRS Class 10, 4+2 max. 85.6 kbps downlink
CSD max. 14.4 kbps
Coding scheme CS 1, 2, 3, 4
Fax PC-Fax Group 3, Class 2
Antenna
850/ 900/ 1800/ 1900 MHz 50 Ω
SMA antenna connector
SIM card 3V or 1.8V plug-in
Power Supply:
Mains supply 230/12V; 0.5A adapter
DC power supply 10 to 16V DC
12V consumption
standby 60mA
call/data typ. 200mA, max. 300mA
Supply connector DC Jack 2.1mm
Telephone Interface:
Interface type 2-wire analog, FXS
Telephone connector type RJ 12, 6/2
Call impedance
600 Ω
Loop voltage 24 V DC
Loop current max. 40 mA
Loop resistance
max. 800 Ω
Tone frequency 425 Hz
Dialing type tone (DTMF) and pulse
Ringing voltage 42 Vrms 50 Hz
Calling line identification CLI during ringing according to ETSI FSK
SMS Sending Input:
Closed loop resistance
max. 1kΩ
Open loop resistance
min. 25kΩ
Input overvoltage protection max. +/- 12V
Serial Interface:
Interface type RS-232C
Connector D-Sub 9 pins
Interface transmission rate 1200 - 115200 bps (autobauding) 8N1
Others:
Dimensions (w/o connectors) 170 x 130 x 45 mm
Operating temperature
0°C to 45°C
Operating status signaling 3 LEDs (on, GSM network, line)

2N EasyGate Specifications

General

Device type	Cellular network gateway
Market positioning	Business
Data network	GPRS, GSM
GSM bands supported	850, 900, 1800, 1900 MHz
GPRS multislot class	10
Input voltage	12 V
Operating temperature (T-T)	0 - 45 °C

Weight and Dimensions

Dimensions (WxDxH)	170 x 130 x 45 mm
