2N EasyGate User Manual

15
8.2. PC based Programming
For programming, connect EasyGate to a PC with a serial cable and make sure that
the EasyGate PCManager is installed. Programming is intuitive and easy. All steps are
accompanied with texts hints above all items you point at with the mouse.
EasyGate data uploading and storing, including firmware upgrade, are executed in a
special mode, in which EasyGate waits for about 3s after power up (all LEDs are on). If
instructed so by the PCManager during this timeout, EasyGate remains in this mode as
long as it is necessary. If EasyGate is not reset after the PCManager is terminated,
switch the system off and on again.
8.2.1. Basic Programming Instructions
1. Run the PCManager and select the language for displaying texts on the right-hand
side.
2. Click on the CD-ROM icon for data handling on the left-hand side.
3. Load data from EasyGate – if EasyGate is not in its special programming mode, you
are invited to switch EasyGate off and on again.
4. Click on the programming table icon on the left-hand side.
5. The parameters are arranged according to their functions in the tables. Set all
parameters you want to change. If you point at a parameter with the mouse, help is
displayed.
6. Click on the CD-ROM icon again for handling data.
7. Save data into EasyGate – if EasyGate is not in its special programming mode, you
are invited to switch EasyGate off and on again.
Language
selection
Data
handlin
g
Programming
tables
Monitoring

2N EasyGate Specifications

General

Device type	Cellular network gateway
Market positioning	Business
Data network	GPRS, GSM
GSM bands supported	850, 900, 1800, 1900 MHz
GPRS multislot class	10
Input voltage	12 V
Operating temperature (T-T)	0 - 45 °C

Weight and Dimensions

Dimensions (WxDxH)	170 x 130 x 45 mm
