Configuration Jumpers
There are no configuration jumpers on the VoIP card.
Example of Correct VoIP Interface Connection
Figure: 2N StarGate / BlueTower
®
Caution
For a successful VoIP card initialisation, the VoIP board MAC address has
to be filled in correctly and the basic CPU must be switched to the
VoIP-SIP mode and contain the VoIP firmware file.
The integrated Ethernet will not work until the VoIP card has been
initialised successfully.
