Others
PIN – PIN code for the SIM cards that request the PIN code. Caution
End of dialling (empty=off) – a selectable DTMF code for DTMF dialling end in
the event of a DISA incoming call. The default value is „#.
List of Emergency Numbers
The window displays a list of emergency numbers, which are normally routed to the
PRI interface. If the PRI line is disconnected, the emergency numbers are dialled
automatically via any GSM/UMTS module according to the following rules:
Search of a logged-in GSM/UMTS module (regardless of free minutes);
Search of a blocked or network searching GSM/UMTS module.
The table includes an exact format of the number to be called (112,911, etc.). The ‘x’
placeholder stands for any digit in the number to be called. The ‘_’ placeholder means
the rest of the number. For example:
Format Allowed numbers
123 123 only
14x0 1400, 1410, 1420, ...1490
999_ All numbers starting with 999
LED Indication
GSM signal mode – set the GSM module signal LED indication.
None
Module1 only
Module2 only
All modules
VoIP Parameters
VoIP Functions
Day of deleting statistics on VoIP (every month) – set the day for
automatic deletion of call statistics via the VoIP interface. None = statistics will
not be deleted automatically.
Note
If there are active calls, restart will be executed 10 seconds after the end
of the last call.
Tip
A SIM card with a PIN code other than that set in the GSM gateway
configuration will be blocked with the „pin-err cause. To unblock the
so-rejected SIM card, enter the correct PIN on your mobile phone!
